There are many factors that can affect the final quality of the SMT patch, such as: the quality of the patch components, the quality of the pads of the pcb circuit board, solder paste, solder paste printing, the placement accuracy of the placement machine, Furnace temperature curve adjustment for reflow soldering, etc. So, author from qihe smt pick and place machine tell you about the most commonly used auxiliary materials in SMT patches: how to choose solder paste and flux?
Distinguish product positioning and differentiate treatment
aThe product has high added value and high stability requirements, so choose high-quality solder paste (R-grade).
b If it is exposed to the air for a long time, anti-oxidation (RA grade) is required.
c For low-end products and consumer goods, those who do not have high requirements for product quality, choose solder paste (RMA) with similar quality and low price.
Device material and PCB pad material
aThe solder paste of 63Sn/37Pb should be selected if the material of the PCB pad is lead tin-plated.
b Devices with poor solderability should use 62Sn/36Pb/2Ag.
Different choices of different processes
a Lead-free process generally chooses Sn-Ag-Cu alloy solder.
bNo-clean products choose weak corrosive no-clean solder paste.
aThe soldering of thermal devices with poor high temperature resistance should choose low melting point solder paste containing Bi.
bHigh temperature components must choose high melting point solder paste.
As the requirements for environmental protection standards are getting higher and higher, the selection of smt chip processing auxiliary materials such as solder paste also has corresponding environmental protection grade requirements, and the application of more lead-free solder paste and no-clean solder paste is becoming more and more popular and applied.
