Today author from QiHe smt pick and place machine sharing you with pcb layout of Controllability and Electromagnetic Compatibility Design of High Speed PCB .High-speed circuit planning is a very complex planning process,
When planning high-speed circuits, there are many elements that need to be considered.
These elements are sometimes antagonistic to each other.

If the layout of high-speed equipment is close to each other, although the delay can be reduced,
However, crosstalk and significant thermal effects may occur.
Therefore, in planning, it is necessary to weigh various elements and make a comprehensive compromise consideration;
It not only meets the planning requirements, but also reduces the complexity of planning.
This article analyzes the PCB layout, layout and high-speed PCB planning in three parts.
Introduce the controllability and electromagnetic compatibility planning of high-speed PCB.

Some experience about High Speed PCB Design PART1: PCB layout,

PCB layout

In PCB design, wiring is an important step to complete product design.
It can be said that the previous preparatory work was done for it,
In the whole PCB, the design process of wiring is most limited, the technology is most detailed, and the workload is most heavy.
PCB wiring includes single-sided wiring, double-sided wiring and multi-layer wiring.
There are also two ways of routing: active routing and interactive routing. Before active routing,
It is possible to pre-route the more stringent lines interactively,
The edges of the input terminal and the output terminal should not be adjacent to each other in parallel to avoid reflection interference.
If necessary, the ground wire should be added for isolation, and the wiring of two adjacent layers should be perpendicular to each other.
Parasitic coupling simply occurs in parallel.

The routing rate of active routing depends on a good layout,
The wiring rules can be pre-set, including the number of bends of the trace, the number of via holes, and the number of steps.
Generally, the exploratory warp line is carried out first, and the short lines are quickly connected, and then the labyrinth wiring is carried out.
First optimize the overall wiring path of the wiring to be laid,
It can disconnect the routed wires as required.
And try to re-route to improve the overall effect.

I feel that through holes are not suitable for the current high-density PCB planning.
It wastes many valuable routing channels, to deal with this contradiction,
Blind hole and buried hole technology appeared, which not only completed the effect of via hole,
It also saves a lot of wiring channels to make the wiring process more convenient.
smoother, more perfect,
The PCB board planning process is a complex yet simple process,
To get a good grip on it,
It is still necessary for the majority of electronic engineering designers to understand by themselves,
In order to get the truth in it.

Today we discuss above issues.You are welcome to express your thoughts in the comments.
Next time we will continue to discuss other aspects.If you need SMT equipment, inquiry is also very welcome.

Read more: Some experience about High Speed PCB Design PART1: PCB layout
