After the PCB board layout is complete, the board should be checked for design rules to ensure that the board meets the design requirements and that all nets are properly connected. So, author from qihe smt pick and place machine tell you about commonly used inspection items in design rule inspection are as follows
a. Whether the distances between lines and lines, lines and component pads, lines and vias, component pads and vias, and vias and vias are reasonable and whether they meet production requirements.
b. Whether the width of the power line and the ground line is appropriate. whether the power supply and the ground line are tightly coupled, and whether there is any place where the ground line can be widened.
c. Whether the best measures have been taken for the key signal lines, such as the shortest length, the protection line, the input line and the output line are clearly separated.
d. Whether the analog circuit and digital circuit have their own independent ground wires.
e. Whether the graphics (such as icons, labels) added to the PCB will cause short circuit of the signal.
f. Whether to modify some unsatisfactory lines.
g. Whether there is a process line on the PCB, whether the solder mask meets the requirements of the production process.whether the solder mask size is appropriate, and whether the character logo is pressed on the device pad.
h. Whether the edge of the outer frame of the power ground layer in the multi-layer board is reduced, such as the exposure of the copper foil of the power ground layer.it is easy to cause a short circuit.
The design rule inspection results can be divided into two types: one is Report (report) output, which generates a report of inspection results
the other is On Line inspection, which is to inspect the electrical rules and wiring rules of the circuit board during the wiring process.Read more: How to verify PCB drawing design fits the SMT PNP
The above is the author from qihe smt pick and place machine wants to sharing with you. If there is some inappropriate content .I hope you can leave a message to tell me and communicate with each other.
