Description
A popular and professional desktop placement machine designed by Qihe SMT team.We used a new design language, combined with the design and production experience of TVM802 series pnp machine to create this pro edition desktop pick and place machine Model TVM802B Plus.
We designed a brand new feeder rack and increased to 58 slots，updated new drive accessories，X,Y axis linear slides,placement head，flight camera，operation panel .It can easily operate LQFP100 pin IC chips and 0402 inch resistor capacitor package .
Such a upgraded highly intelligent, efficient and affordable desktop placement machine. It’s an excellent partner for development, design and business establishment.
Brand new operation panel, with LED ring light button, more convenient for you to observe and operate.
We have adopted the detachable combined packaging of the external equipment, in order to facilitate transportation and reduce the freight cost of customers.
A smart desktop pick and place machine for Hobbiest/Low vol Usag support mostly 0402,0603, 0805, TSSOP, SOIC, TQFP, QFNs
| Model | TVM802B Plus |
| Min applicable PCB size | 20*20mm |
| Max applicable PCB size | 300*320mm |
| Max xy moving range | 490*440mm |
| Max z moving range | 12.5mm |
| Placement head quantity | 2 |
| Max mounting capability | Vision on: 5500pcs/h Vision off: 6500pcs/h |
| Feeder slots & Tape width | standard 58 slots （8mm=50, 12mm=6,16mm=2） |
| Applicable component | Resistor/Capacitor size:0402-5050 inch, Largest size:LQFP100 SOP,TQFP,QFN… |
| Dual Visual system | One HD inspection camera One high speed Flight camera |
| Lack detection | Vacuum detection |
| Work power | 280W |
| Power supply | 220V/110V |
| Net weight | 55kg |
| Gross weight | 70kg |
| Machine size | L675*W890*H340mm(With monitor assembled) L675*W1250*H340mm(With feeder slots device assembled ) |
| Volume | 0.4CBM |
